Drinkers
|
Model
| | WaterMaster 1200 | |
Length (in/cm)
| | 144 / 366 | |
Width (in/cm)
| | 24 / 61 | |
Overall Ht (in/cm)
| | 28.5 / 72 | |
Drinking Ht (in/cm)
| | 24 / 61 | |
Shipping Wt (lbs/kg)
| | 250 / 113 | |
Heat (CF=Constant Flow)
| | CF Opt/Opt Immersion & Self Reg. Heat Cable | |
Trough Capacity (gal/liter)
| | 60 / 227 | |
Animal Capacity
| | 500 Beef / 250 Dairy |
|
Model
| | WaterMaster 96 | |
Length (in/cm)
| | 96 / 244 | |
Width (in/cm)
| | 33 / 84 | |
Overall Ht (in/cm)
| | 28 / 71 | |
Drinking Ht (in/cm)
| | 22 / 56 | |
Shipping Wt (lbs/kg)
| | 200 / 91 | |
Heat (CF=Constant Flow)
| | CF Std/Opt Immersion & Self Reg. Heat Cable | |
Trough Capacity (gal/liter)
| | 75 / 284 | |
Animal Capacity
| | 300 Beef / 150 Dairy |
|
Model
| | Omni | |
Length (in/cm)
| | 28.3 / 72 | |
Width (in/cm)
| | 14.5 / 37 | |
Overall Ht (in/cm)
| | 25 / 64 | |
Drinking Ht (in/cm)
| | 18 / 46 | |
Shipping Wt (lbs/kg)
| | 45 / 20 | |
Heat (CF=Constant Flow)
| | Std Electric | |
Watts (Amps)
| | 298W (2.5A@120V) | |
Trough Capacity (gal/liter)
| | 2.2 / 8 | |
Animal Capacity
| | 40 Beef / 60 Calves |
6000-6001
| Specifications |
| Capacity | 250 head beef
100 head dairy | | Gallons | 60 (up to 30 gallons more than the competition) | |
Length | 90" | Width | 33" | | Drinking Height | 24" (2" higher than the competition)
|
Constant flow or optional electric heating.
6200/6201
| Specifications |
| Capacity | 150 head beef or 70 head dairy | | Gallons | 60 | |
Length | 84" | Width | 22" | | Drinking Height | 24"
| | Weight | 150 pounds
|
Automatic refill or constant flow Optional electric heating.
| |
